High Tg PCBs or high glass transition temperature PCBs are specialized printed circuit boards designed to perform reliably in high-temperature conditions. They are featured with:
| Specification | Value |
|---|---|
| Materials | Rogers 4350B, Nelco N4000-13,Isola 370HR, NP-175TL... |
| Tg Value | 180-280°C |
| Board thickness | 0.8- 5.0 mm |
| Min. Board size | 10*10mm |
| Max. Board size | 570*1200mm |
| PCB size tolerance | ±0.2-0.3mm |
| Thermal decomposition | > 300°C |
| Flammability | UL94V-0 |
| Copper thickness | 0.5-5 OZ |
| Surface Finishes | HASL, ENIG, OSP, and others |
| Certifications | UL, IPC-6012, RoHS, ISO 9001, ISO14001 |
As one of the top High Tg PCB manufacturers , we offer qualified as well as customized PCB manufacturing services to meet the needs of customers.
Custom Design
and Prototyping
Our engineer customize aluminum PCB designs according to your requirement and provide you with efficient prototyping solutions.
Advanced
Manufacturing
We manufacture single layer to multilayer aluminum PCBs using state of the art technology to ensure high accuracy and repeatability.
Quality
Assurance
All the circuit boards to be sold are tested for AOI, X-ray, and electrical testing before delivery to our customers.
Technical
Support
Our support team is tailored to meet your needs from the very beginning of your collaboration with us to after completing your order.
UnityPCB’s 12,400㎡ facility includes a 2,600㎡ clean room, 5 SMT lines, and 3 DIP production lines. Equipped with precision drilling machines, plating systems, and etching setups for exact circuit patterning, as well as reflow soldering machines and wave soldering systems. Our state-of-the-art X-Ray and AOI machines ensure the high-quality PCB production.
This type of PCB has the capability to withstand high temperatures up to 170°C, it is applied in use situations that experience higher temperatures
These materials include the High Tg FR-4, Isola 370 HR, Rogers 4350B, Nelco N4000-13, Taconic TLY, Panasonic R-1755, Ventec VT-4B and TUC TU-883.
The thermal conductivity of High Tg circuit boards is much higher than that of standard PCBs due to the higher thermal resistance of Tg substrates.
Yes, at UnityPCB we provide support in the design and engineering process to ensure your High Tg PCB design can effectively be manufacturing and performs in the intended manner.
Available surface finishes include HASL, HASL Lead-Free, ENIG, Immersion Silver, Immersion Tin, and OSP.
The turn around time for High Tg PCBs can take a bit longer and normally takes between one and two weeks depending on the order forms complexity and the quantity ordered.
