UnityPCB offers high-frequency PCB services to ensure top signal integrity and performance.
High frequency PCB is used for the transmission of signals at much higher frequencies than the standard frequencies. They are featured with:
| Specification | Value |
|---|---|
| Base material | PTFE (Polytetrafluoroethylene), FR-4, Rogers, etc. |
| Frequency range | 500MHz to 2GHz |
| Board thickness | 0.8- 5.0 mm |
| Min. Board size | 10*10mm |
| Max. Board size | 570*1200mm |
| PCB size tolerance | ±0.2-0.3mm |
| Flammability | UL94V-0 |
| Copper thickness | 0.5-5 OZ |
| Surface Finishes | HASL, ENIG, OSP, and others |
| Certifications | UL , IPC-6012, RoHS, ISO 9001, ISO14001 |
As one of the top high frequency PCB manufacturers, we offer qualified and customized PCB manufacturing services to meet the needs of customers.
Custom Design
and Prototyping
Our engineer customize aluminum PCB designs according to your requirement and provide you with efficient prototyping solutions.
Advanced
Manufacturing
We manufacture single layer to multilayer aluminum PCBs using state of the art technology to ensure high accuracy and repeatability.
Quality
Assurance
All the circuit boards to be sold are tested for AOI, X-ray, and electrical testing before delivery to our customers.
Technical
Support
Our support team is tailored to meet your needs from the very beginning of your collaboration with us to after completing your order.
UnityPCB’s 12,400㎡ facility includes a 2,600㎡ clean room, 5 SMT lines, and 3 DIP production lines. Equipped with precision drilling machines, plating systems, and etching setups for exact circuit patterning, as well as reflow soldering machines and wave soldering systems. Our state-of-the-art X-Ray and AOI machines ensure the high-quality PCB production.
A high-frequency PCB is a type of circuit board that is specifically developed for high-speed digital or RF signals without much signal loss or interference.
The characteristics include low loss material, precise tolerance, specific layering, controlled impedance, controlling of signals and the ability to accommodate multigigahertz data rate.
Typical materials are PTFE (Polytetrafluoethylene), FR4, Rogers, and other types of specialized laminates with low dielectric losses and high thermal conductivity.
To address these high-frequency concerns, UnityPCB relies on cutting-edge fabrication methods including micro-etching, controlled signal traces, fine line and spatial accuracy and material surface treatments.
Yes, UnityPCB can provide lead-free manufacturing solutions for High Frequency PCBs to follow regulatory requirements and to facilitate use of lead-free solder.
Indeed, UnityPCB provides custom solutions for high frequency circuit boards, which means that we can work on a specific requirement in terms of High Frequency PCBs to help with a variety of HF applications.
