Push the boundaries of high-density interconnect technology with UnityPCB's advanced HDI PCBs.
We provide the best HDI PCB services at UnityPCB, manufacturing superior high-density interconnect circuit boards suitable for intricate electronic applications. Their features include:
| Specification | Value |
|---|---|
| Layers | Up to 18 layers |
| Board Thickness | 0.8- 5.0 mm |
| Min. Board size | 10*10mm |
| Max. Board size | 570*1200mm |
| PCB size tolerance | ±0.2-0.3mm |
| Min. mechanical drill | 0.1 mm |
| Min. Line Spacing | 4mil - 7mil |
| Impedance control | Yes |
| Copper weight | 0.5-5 oz |
| Surface Finishes | HASL, ENIG, OSP, and others |
| Certifications | UL , IPC-6012, RoHS, ISO 9001, ISO14001 |
As one of the top HDI PCB manufacturers , we offer qualified as well as customized PCB manufacturing services to meet the needs of customers.
Custom Design
and Prototyping
Our engineer customize aluminum PCB designs according to your requirement and provide you with efficient prototyping solutions.
Advanced
Manufacturing
We manufacture single layer to multilayer aluminum PCBs using state of the art technology to ensure high accuracy and repeatability.
Quality
Assurance
All the circuit boards to be sold are tested for AOI, X-ray, and electrical testing before delivery to our customers.
Technical
Support
Our support team is tailored to meet your needs from the very beginning of your collaboration with us to after completing your order.
UnityPCB’s 12,400㎡ facility includes a 2,600㎡ clean room, 5 SMT lines, and 3 DIP production lines. Equipped with precision drilling machines, plating systems, and etching setups for exact circuit patterning, as well as reflow soldering machines and wave soldering systems. Our state-of-the-art X-Ray and AOI machines ensure the high-quality PCB production.
HDI (High Density Interconnect) PCBs are circuit boards that have high density interconnecting features, giving the circuit board little size, high functions.
Advanced high density interconnec PCBs employ special laminates like LCP, ABF, RCC, and low loss dielectric materials as they possess high density and performance capabilities.
Microvias are the small blind via holes that can be used to make high density vertical connection between the layers and increase performance of the circuit in the regions of small area.
Challenges of manufacturing micro devices are the ability to control micro-features, the nature of manufacturing process that involves the use of sophisticated methods such as laser drilling as well as plasma etching, material and process control and some special design rules.
Yes, UnityPCB Company have the ability to produce the high density interconnec PCBs with the layer count up to 18.
Absolutely. At UnityPCB, we offer comprehensive design review and DFM (Design for Manufacturing) services to ensure your HDI circuit boards are optimized for manufacturability.
